Тоног төхөөрөмж нийлүүлэх сонгон шалгаруулалт зарлаж байна №2

МҮОНРТ-д сансрын хиймэл дагуулаас сигнал хүлээж авах, дамжуулах тоног төхөөрөмжийн нийлүүлэгчийн сонгон шалгаруулалтанд урьж байна.

Тавигдах ерөнхий шаардлага:

- Тухайн чиглэлийн үйл ажиллагаа эрхэлдэг туршлагатай байх
- Үйл ажиллагаа эрхлэх холбогдох зөвшөөрөлтэй байх /ААН-н гэрчилгээ болон бусад холбогдох тусгай зөвшөөрлийн хуулбарууд нотариатаар баталгаажуулсан/
- Санхүүгийн чадамжтай байх /сүүлийн 2016, 2017 оны санхүүгийн тайлангийн хуулбар/
- Мэргэжлийн чадварлаг хамт олон байх

Техникийн нөхцөл, тодорхойлолт

№ Төхөөрөмжийн нэр Техникийн үзүүлэлт 1 Сансрын хүлээн авагч 1x ASI input transport stream input Front panel control Web browser and SNMP remote control Alarm relay and SCTE 35 controlled contact closures for ad-insertion signalling. Base unit includes MPEG-2 and MPEG-4 4:2:2 decoder card Cooling integrated fan SATELLITE INPUT: Connector: 4x F-Type (F), 75 Ohm Modulation: DVB-S QPSK, DVB-S2 QPSK, 8PSK, 16APSK demodulation with license keys Standard: EN300 421 Frequency range:950 MHz to 2150 MHz/ Input level: -25 dBm to -65 dBm Symbol rate: 1 Msyms to 45 Msyms (DVB-S),1(5) Msyms to 31 Msyms Bit rate: 81Mbps up to 170Mbps max FEC, DVB-S: 1/2, 2/3, 3/4, 5/6, 7/8 FEC, DVB-S2:1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10 LNB Power: 13V, 18V, 22 kHz on/off ASI TRANSPORT STREAM INPUT: Connector:1x BNC (F) 75 Ohm Max. input rate: 160 Mbps Packet length: 188/204 byte packets Standard: EN50083-9 100/1000BaseT Input: · MPEG transport stream over IP · 2x 100/1000BaseT input · Very low latency ·Enables SMPTE 2022 Pro-MPEG FEC capability for the IP input card · Requires IP input card Frame Sync Input · Synchronizes the IRD to the house black and burst reference · Frame Sync functionality often partners 4:2:2 decoding applications Input Redundancy: ·Redundancy switching from primary to secondary input triggered by presence of null packets in the incoming stream · User definable percent of null packets to trigger redundancy switch · Standard automaticredundancy switching between ASI input and the additional input VIDEO AND TRANSPORT STREAM OUTPUT: Video Processing: 4 : 2 : 2 10 bit Video formats: HD-SDI 1080/50i (HD-SDI: HD Serial digital (SMPTE 292M)), SD-SDI 720/50i (SD-SDI: SD Serial digital (SMPTE 259M)) SD Video and ASI Output · 2x composite video outputs · 2x switchable ASI/SDI outputs 3 Gbps HD and SD Video and ASI Output · 1x composite video output · 1x RGB/YPrPbanalog video output · 3x switchable ASI/SDI/HD-SDI outputs with embedded audio · 3 Gbps HD-SDI output compatible with MPEG-4 4:2:2 1080i50/60 capability · Simultaneous presentation of HD and SD on video output interfaces Embedded Audio: SMPTE 299M (HD)SMPTE 272M (SD) Embedded Audio Channels: two, four or six stereo pairs IP Transport Stream Output · Encapsulation of transport stream output into IP multicast · MPTS or single SPTS output stream with licence key · 2x Gigabit Ethernet RJ-45 interfaces capability BISS CA · BISS Mode 1 and BISS Mode E descrambling BISS Multi-service CA · Multi-service decryption for BISS Password Protection of Web Browser ·Protects Web browser from malicious or accidental changes STREAM PROCESSING: Single Service Filtering · Filter multiple services to output a single service · Re-map PIDs for the outgoing service Multi-Service Filtering ·Filter N multiple incoming services to M outgoing services · Re-map PIDs for a single service · CBR MPTS transport stream output · Service splitting for multiple IP SPTS output VIDEO DECODING MPEG-2&4 HD&SD 4:2:2, 4:2:0 Decoding DATA and CONTROL: Front panel keypad and LCD SNMP control, traps and alarms Web browser RS232 Remote Control and Data · RS232 remote control - Alteia protocol · RS232 data output High speed IP data output · MPE based data de-encapsulation of IP data · Requires IP TS output AUDIO: Decoded audio is embedded in (HD)SDI outputs and output via physical audio interfaces Balanced Audio Output · 2x stereo pairs of balanced analog and digital outputs Unbalanced Audio Output ·2x stereo pairs of unbalanced digital outputs AAC Audio decode · 2x AAC-LC and HE-AAC decoding XLR Terminal Audio Break-Out Cable · Provides XLR terminal connections for analogue and digital audio output · 1x stereo pair per breakout cable via 2x XLR connectors Screw Terminal Audio Break-Out Cable · Provides screw terminal connections for analog and digital audio output · 1x stereo pair per breakout cable via 2x Screw terminal connectors Power requirements: AC220-240V, 50Hz 2 Тавган антенн Одоо хэрэглэгдэж буй 4,5 метр диаметртэй тавган антеннийг ашиглана. 3 Хиймэл дагуулын LNB · Input Frequency: C Band: 3.4-- 4.2GHz · L.O. Frequency: C Band: 5150MHz · Output Frequency: C Band: 950 to 1750 MHz · L.O. Leakage Input Port: 45dBm · L.O. Stability: ±2MHz (-40centigrade to +70centigrade) · Noise Figure): C band :< 17°K typ KU band: 0.2db LO Phase Noise @ 1Khz -72dBc LO Phase Noise @ 10Khz -81dBc LO Phase Noise @ 100Khz -90dBc · Conversion Gain: C band: 65dB (min) KU band: 60db (min) Gain Flatness: ±1 dBm (max) Input VSWR: 2.5:1(max) Output VSWR: 2.0:1(max) Temperature Range -22 ~ +140°F / -40 ~ +60°C Output Connector: F-female Connector Control Signals Ca V/CR - 11.5 ～ 14.0V Control Signals Cb [ H/CL] -16.0 ～ 20.0V Output 2 ( Simultaneous horizontal and vertical output )

Тоног төхөөрөмж нийлүүлэх үнийн санал, нийлүүлэх хугацаа, тоног төхөөрөмжийн танилцуулгыг битүүмжлэн 2018 оны 05 сарын 04-ний 16 цагт багтаан ирүүлнэ үү.

Хаяг: Баянгол дүүрэг 11-р хороо Хувьсгалын зам-3
МҮОНРТ өөрийн байр, санхүүгийн өрөө
Утас: 70117004 /дотуур 2206/
