Төхөөрөмжийн нэр

Техникийн үзүүлэлт

Тоо хэмжээ

1

Дэ-модулятор

•NS4 technology

• Scalable from 100Kbps to 425Mbps with built-in NovelSat DUET™ CeC™ (carrier-echo-cancellation)

• DVB-DSNG, DVB-S, DVB-S2 & DVB-S2X standard compliant

• Embedded TCP acceleration, compression & optimization

• Radio Frequency Interference (RFI) Mitigation software

package

• 10-15dB stronger jamming immunity

• Up to 80Msymbols/sec

• Optimized ACM mode

• NovelSat DDC™ - Dynamic Distortion Compensator (non-linear processing mode for saturated signals)

• IP routing/switching/bridging capabilities

• Advanced QoS

• NSPE IP Encapsulation

• QPSK, 8PSK, 16APSK, 32APSK, 64APSK

•Gigabit Ethernet, E1/T1, ASI interfaces

• OC-3/STM-1 , OC-3 interface

• 24V/48V integrated BUC feeder

• IF output mode 50MHz-180MHz

• 10MHz reference In/Out

• Dual ASI output interface

• Dual Ethernet 10/100 1Gb output interface

• ACM mode

• Dual-channel mode

• Supports N+1 redundancy

• Carrier ID (CID) compatible

• TSoIP Support

LNB POWER CONTROL

Voltage:11.5-14 V (Vert. Pol.), 16-19V (Horiz. Pol.)

Band select:22KHz ±4KHz

Max. current:350mA

1 иж бүрдэл
