1.       Удирдлагын компьютер – 2 ширхэг

1

CPU

i7-9700 3.0Ghz

2

RAM

8GB DDR4 2666MHz болон түүнээс дээш

3

HARD DISK

1TB 7.2K RPM or 500GB SSD

4

GRAPHIC CARD

4GB

5

Drive

DVDRW

6

DISPLAY

22” LED Monitor

№

2.       Thunderbolt 3 PCie card – 4 ширхэг

1

TRANSFER SPEEDS

up to 40 Gbps

2

PORTS

One Type-C port supports Thunderbolt 3, USB 3.1 and DisplayPort 1.2 Includes secondary USB 3.1 Type-A port

№

3.     Сүлжээний карт 10Gb – 3 ширхэг

1

Interface

10GBASE-T Ethernet

2

PORTS

2

№

4.     SFP Module 10Gb – 2 ширхэг

1

Form Factor

Optical Fiber

2

Ethernet Technology

10 Gigabit Ethernet

3

Network Technology

10GBase-SR

4

Product Type

SFP+

5

Interfaces / Ports Details

1 x 10GBase-SR Network

№

5.     Архивын оруулгын сервер – 1 ширхэг

/TS-1277XU-RP-1200-16G болон түүнтэй дүйцэхүйц/

1

CPU

AMD Ryzen™ 3 1200 quad-core 3.1 GHz processor, Turbo Core 3.4 GHz

2

CPU Architecture

64-bit x86

3

Encryption Engine

Yes (AES-NI)

4

System Memory

16 GB UDIMM DDR4 (4 x 4GB)

5

HDD

4TBx12

6

Flash Memory

5GB (Dual boot OS protection)

7

Drive Bay

12 x 3.5-inch SATA 6Gb/s, 3Gb/s

8

Gigabit Ethernet Port

(RJ45) 2

9

10 Gigabit Ethernet Port

2 x 10GbE SFP+ SmartNIC port

10

PCIe Slot

4 x Gen 3

11

USB 3.2 Gen 2 (10Gbps) Port

1 x Type-C USB 3.2 Gen 2 5V/3A 10Gbps

1 x Type-A USB 3.2 Gen 2 5V/1A 10Gbps

12

Form Factor

2U Rackmount

13

Power Supply

Unit 300W (x2), 100-240V

14

Rack rail

RAIL-B02

15

Operating System

embedded Linux /QTS 4.3.4/

№

6.       Сүлжээний 10Гигабит хурдтай свитч – 1 ширхэг

/QSW-1208-8C болон түүнтэй дүйцэхүйц/

1

Number of Ports

12

2

10GbE SFP+

4

3

10GbE SFP+/RJ45 Combo Ports

8

4

Power Supply Description

Internal Open Frame

5

Max. Power Consumption

50W

6

Input Power Type

AC

7

Input Voltage Range

100-240VAC, 50/60 Hz

8

MAC Address Table

27K

9

Total Non-Blocking Throughput

120Gbps

10

Switching Capacity

240Gbps

11

Console (Opt.)

RS232

12

Fan

 System: 2 x 4 cm (12V DC)

13

Supported Standards

IEEE 802.3ab 1000BASE-T Gigabit Ethernet
IEEE 802.3bz 2.5G/5G BASE-T Multi-Gig Ethernet
IEEE 802.3an 10GBASE-T 10G Ethernet
IEEE 802.3ae 10GBASE-SR
IEEE 802.3ae 10GBASE-LR
IEEE 802.3x Full-duplex flow control

14

LED Indicators

Per Port: Speed/Link/Activity
Per System: Power/Status

15

Certifications

CE, FCC, VCCI, BSMI RCM, CCC

16

Jumbo Frames

9K

17

Operating Temperature

0°C to 40°C (32°F to 104°F)

18

Weight (Net)

2.15 kg

19

Electromagnetic Compliance

CLASS A, UL62368

20

Warranty

1 year

№

7.       Сүлжээний кабель - 1 хайрцаг /300м/

1

UTP cable

Category 6 cable
